| No. | 1 | 2 | 3 | 4 | 5 | |
|---|---|---|---|---|---|---|
| MOTOR | 3.7Kw | 5.5Kw | 7.5Kw | 11Kw | 15Kw | |
| POWER | 440VAC 60Hz, 3PHASE, TEFC Type | |||||
| MOTOR SPEED (RPM) | 3505 | 3510 | 3510 | 3515 | 3525 | |
| Motor Torque(N.m) | 10.1 | 15 | 20.6 | 29.9 | 40.6 | |
| Efficiency | at 1/2 Load | 84.50% | 85.50% | 87.20% | 87.20% | 87.20% |
| at 3/4 Load | 86.50% | 87.50% | 89.20% | 89.20% | 89.20% | |
| at Full Load | 87.50% | 88.50% | 90.20% | 90.20% | 90.20% | |
| Air Volume(CMM) | < 11 | < 21 | < 31 | < 46 | < 61 | |
| Static Pressure | 632.6 mmAq | |||||
| Design Temp. | 20℃ | |||||
